The F6001D Single-Duct Fume Extractor provides localized extraction of solder smoke, fine airborne particles and compatible process fumes around electronics assembly, PCB rework, repair and engineering workstations.

Its flexible extraction duct can be positioned close to the emission point for more effective source capture. According to OSHA’s local exhaust ventilation guidance, local extraction systems are designed to capture contaminants at or near their source before they spread into the workplace.

Powered by an 80W extraction system, the F6001D delivers a rated airflow of 235 m³/h and air velocity of 17 m/s. Its three-layer filtration system provides a published particle filtration efficiency of 99.97% at 0.3 µm. Digital controls, remote operation and a filter-clogging alert help simplify daily operation and maintenance monitoring.

Explore more fume extractors from Biz One or browse our complete range of engineering products in Malaysia. Biz One’s current engineering range also includes desktop and dual-duct extraction options.

Recommended Applications

The F6001D may be considered for:

• Electronics soldering and de-soldering
• PCB assembly, repair and rework
• Electronics maintenance workstations
• Precision component assembly
• Laboratories and research areas
• Engineering and technical workshops
• Compatible light industrial processes

Suitability depends on the contaminant, process temperature, emission volume, filter media and duct position. Chemical vapours, laser emissions or hazardous contaminants should be reviewed before selecting the filtration system.

Technical Specifications

Frequently Asked Questions

What is the F6001D fume extractor used for?

It is designed for localized fume and particle extraction around soldering, electronics assembly, PCB rework, repair and compatible technical workstations.

How many extraction ducts does the F6001D have?

The F6001D has one flexible Ø75 mm extraction duct measuring approximately 1.4 metres.

When should the filters be replaced?

The built-in filter-clogging alarm helps indicate when the filters require inspection or replacement. Actual replacement frequency depends on contaminant loading and daily operating time.

Is the F6001D suitable for chemical or laser fumes?

Suitability depends on the generated contaminant and installed filter media. Contact Biz One Malaysia with your process details so the application can be reviewed before purchase.
