The F6002D Dual-Duct Fume Extractor is designed to capture smoke, airborne particles and compatible process fumes close to their point of generation. Its two extraction ducts can be positioned around production equipment, work benches or separate local emission points, making the unit suitable for operations that require flexible source capture.

A 200W extraction system delivers a rated airflow of 2 × 150 m³/h, while the three-layer filtration configuration provides a published particle filtration efficiency of 99.97% at 0.3 µm. The unit also incorporates an intelligent digital control panel, remote control and a filter-clogging alert to simplify routine operation and maintenance monitoring.

Its compact housing and castor wheels allow the extractor to be repositioned between workstations where required. With published operating noise below 55 dB, it is suitable for controlled production and technical work environments where excessive equipment noise may be disruptive.

Key Features

• Two extraction ducts for localized fume capture at two positions
• 200W extraction power
• Rated airflow of 2 × 150 m³/h
• Three-layer filtration configuration
• Published filtration efficiency of 99.97% at 0.3 µm
• Intelligent control panel with digital display
• Remote control for convenient operation
• Filter-clogging alarm for maintenance notification
• Flexible Ø75 mm extraction ducts
• Castor wheels for easier workstation repositioning
• Operating noise below 55 dB
• Compact industrial housing

These features and performance figures are based on the published F6002D product specifications.

Operational Benefits

Dual-Point Extraction

The two-duct configuration allows extraction to be positioned near two fume-generating points. This can support a dual-station arrangement or two capture positions around one machine, depending on the process layout.

Easier Equipment Control

The digital control panel provides a clearer operating interface, while the remote control allows settings to be adjusted without repeatedly accessing the machine body.

Maintenance Notification

The filter-clogging alert helps operators identify when filtration performance may be affected by accumulated contaminants. Replacement intervals will depend on the process, contaminant loading and daily operating duration.

Flexible Workstation Placement

Castor wheels and relatively compact dimensions allow the extractor to be repositioned around production benches, laboratory stations and technical work areas.

Lower-Noise Operation

A published noise level below 55 dB makes the unit more appropriate for indoor production and technical environments than high-noise extraction equipment.

Recommended Applications

The F6002D may be considered for:

• Electronics soldering and de-soldering stations
• Printed circuit board assembly and rework
• Electronics repair and maintenance benches
• Semiconductor production support areas
• Precision component assembly
• Laboratory and research workstations
• Small-format laser marking or engraving
• Technical training and engineering workshops
• Compatible thermal or manufacturing processes
• Production equipment requiring two local capture points

Application suitability depends on the contaminant, process temperature, emission rate, duct position and installed filter media. Local exhaust ventilation performs best when its capture point is positioned close to the emission source, and the filtration system must be appropriate for the contaminant being generated.

Technical Specification
